Back to Rotary tillers VLSC
The VLSC series is suitable for 40 hp to 75 hp tractors and has a Cat. 2 hitch, with hydraulic side shift. The VLSC models are designed for the applications in vineyards and orchards where a in-row tillage is required. Rotor speed is adjustable.
Models available
607284
Recommended horse power
40-70 CV
Good for
Rotary tillers
Standard Equipment
Data Sheet
| VLSC 60 | VLSC 72 | VLSC 84 | ||
|---|---|---|---|---|
| Overall dimension | mm | 1743x1000x1165 | 1995x1000x1165 | 2250x1000x1165 |
| Tilling width | mm | 1500 | 1750 | 2000 |
| Tractor HP range | - | 40+45 | 50-65 | 65-70 |
| 3-point hitch type | CAT. 2 | |||
| No. of flanges on rotor | 7 | 8 | 9 | |
| No. of tines per flange | 6 | |||
| Number of tines | 42 | 48 | 54 | |
| Size of blade | Curved | |||
| Dimensions of tines | mm | 190x108x7 | ||
| PTO input speed | rpm | 540 | ||
| Rotor shaft speed | rpm | 241 | ||
| Side transmission drive | Gears | |||
| Max working depth | mm | 200 | ||
| Rotor tube diameter | mm | 89 | ||
| Rotor swing diameter | mm | 485 | ||
| Weight | Kg | 524 | 556 | 586 |
Video
Guarda il video del prodotto VLSC
Optional
Left rotor
