Back to Rotary tillers VL
The VL series is suitable for tractors from 35 to 75 hp with category 2 hitch.
The VL models are medium/heavy-duty and dependable on very demanding and stony soils. The speed of the rotor can be adjusted.
Models available
53607284
Recommended horse power
35-75 CV
Good for
Rotary tillers
Standard Equipment
Data Sheet
| VL 53 | VL 60 | VL 72 | VL 84 | ||
|---|---|---|---|---|---|
| Overall dimension | mm | 1650x940x720 | 1775x940x720 | 1970x940x720 | 2259x845x1200 |
| Tilling width | mm | 1500 | 1650 | 1850 | 2100 |
| Tractor HP range | - | 35-50 | 40-55 | 50-65 | 65-75 |
| 3-point hitch type | CAT. 2 | ||||
| No. of flanges on rotor | 6 | 7 | 8 | 9 | |
| No. of tines per flange | 6 | ||||
| Number of tines | 30 | 36 | 42 | 48 | |
| Size of blade | Curved | ||||
| Dimensions of tines | mm | 190x108x7 | |||
| PTO input speed | rpm | 540 | |||
| Rotor shaft speed | rpm | Multispeed | |||
| Side transmission drive | Gears | ||||
| Max working depth | mm | 200 | |||
| Rotor tube diameter | mm | 89 | |||
| Rotor swing diameter | mm | 480 | |||
| Weight | Kg | 397 | 410 | 447 | 484 |
